Cảm biến tiệm cận Omron E2B-M18LS08-M1-C1

Thông số kỹ thuật cảm biến tiệm cận Omron E2B-M18LS08-M1-C1

• Sensing distance: 8 mm ± 10%
• Setting distance: 0 to 6.4 mm
• Differential travel: 10% max. of sensing distance
• Detectable object: Ferrous metal (The sensing distance decreases with non-ferrous metal.)
• Standard sensing object (mild steel ST37): 24 × 24 × 1 mm
• Response frequency *1: 500 Hz
• Power supply voltage: 10 to 30 VDC. (including 10% ripple (p-p))
• Current consumption: 10 mA max.
• Output type: -B models: PNP open collector
  -C models: NPN open collector
• Control output Load current: 200 mA max. (30 VDC max.)
• Control output Residual voltage: 2 V max. (under load current of 200 mA with cable length of 2 m)
• Indicator: Operation indicator (Yellow LED)
• Operation mode (with sensing object approaching): -B1/-C1 models: NO
  -B2/-C2 models: NC
• Protection circuit: Output reverse polarity protection, Power source circuit reverse polarity protection,
  Surge suppressor, Short-circuit protection
• Ambient air temperature: Operation and storage: -25 to 70°C (with no icing or condensation)
• Temperature influence: ±10% max. of sensing distance at 23°C within temperature range of -10 to 55°C
  ±15% max. of sensing distance at 23°C within temperature range of -25 to 70°C
• Ambient humidity: Operation and Storage: 35 to 95%
• Voltage influence: ±1% max. of sensing distance in 24 VDC ±15%
• Insulation resistance: 50 MΩ min. (at 500 VDC) between current-carrying parts and case
• Dielectric strength: 1,000 VAC at 50/60 Hz for 1 min between current-carrying parts and case
• Vibration resistance: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y and Z directions
• Shock resistance: 1,000 m/s , 10 times each in X, Y and Z directions
• Standard and listings: (1) IP67 (IEC60529) (2) EMC (EN60947-5-2)
• Connecting method: Pre-wired models (standard is 4 mm dia. PVC cable with length = 2 m, 5 m).
  Connector models (M12-4pin)
• Weight (packaged) Pre-wired model: Short body: Approx. 95 g, Long body: Approx. 110 g *2
• Weight (packaged) Connector model: Short body: Approx. 60 g, Long body: Approx. 80 g
• Material Case: Brass-nickel plated
• Material Sensing surface: PBT
• Material Cable: Standard cable is 4 mm dia. PVC.
• Material Clamping nut: Brass-nickel plated
• Material Toothed washer: Zinc-plated iron
